Four-Hopper Cut-Gate Packer Scale with electromagnetic feeder FNL-0512CV-04

New solution for small to large bags

  • Multihead Scale



  • High Speed  Max.40wpm
  • High Accuracy  +/- 2.0g
  • Small to Large  100g~20kg
  • Easy operation  User friendly

■Covers wide rage of your weighing needs

The Yamato new packer scale FNL-0512CV-04 will be your new weighing solution.
Specially designed for small to large bags from 100g to 20kg with high accuracy.

“Cut-gate” for full feed and “Electromagnetic feeder” for dribble feed make possible
to weigh Wide variety of granular products,  such as Rice, Seeds, Sugar, Resin pellet,
Pet food, Coffee beans and Detergent powder, Fertilizer etc.


No. Subject Spec
1 Capacity Max. 40B/M
2 Main Body 7L Weighing Hopper with Cut-Gate ×4set
and Electric-magnetic feeder×4set
3 Feed System Air Cylinder(Cut-Gate), Electric-magnetic feeder
4 Weighing range 2000g  5000g
5 Weighing Accuracy(2σ) +/-2g  +/-4g
6 Min. graduation 1g
7 Weighing method Net weighing
8 Power Supply 1-phase AC220V±10% 50/60Hz
9 Power Consumption 1.0kVA
10 Air pressure/Air consumption 0.5MPa/100NL/min
11 Weighing Products Free flowing Granular Materials (Seeds, Resin Pellets, Rice, Grains, Fertilizer etc. )
